Refer to the exhibit (building subjected to wind with force diagrams A, B, C, D).

The diagram shows a building exposed to wind loading, which causes lateral pressure (P_w) on the windward wall and suction (negative pressure) on the leeward wall, generating an overturning moment about the base of the building.

Diagram A correctly shows:

The wind pressure (P_w) pushing on the windward wall, producing a lateral force applied at approximately two-thirds the building height (h), which tends to overturn the building.

The wind suction (P_l) pulling on the leeward wall, acting in the opposite direction but also contributing to the overturning moment.

The reaction forces at the base resist this overturning: an uplift force (negative vertical reaction) on the windward side and a downward force on the leeward side, counterbalancing the moment.

Diagrams B, C, and D incorrectly orient or place the forces or reactions, failing to accurately depict the overturning moment and the corresponding resisting forces.

NCARB ARE 5.0 PPD guidelines on environmental conditions emphasize understanding wind load effects, including lateral pressures, suction, overturning moments, and foundation reactions essential for structural design and safety.
