Exhibit.

Device Group Hierarchy

Shared

DATACENTER_DG

DC_FW_DG

REGIONAL_DG

OFFICE_FW_DG

FW-1_DG

Analysis

Considerations:

FW-1 is assigned to the FW-1_DG device group.

FW-2 is assigned to the OFFICE_FW_DG device group.

There are no objects configured in REGIONAL_DG and OFFICE_FW_DG device groups.

The address object Server-1 appears in multiple device groups with different IP addresses. The device groups have a hierarchy, which means objects can be inherited from parent groups unless overridden in the child group.

FW-1_DG:

Server-1 has IP 4.4.4.4, which will be pushed to FW-1 because it is in the FW-1_DG device group.

OFFICE_FW_DG (for FW-2):

Since there are no objects in OFFICE_FW_DG and REGIONAL_DG, FW-2 will inherit from Shared.

In the Shared group, Server-1 has IP 1.1.1.1.
