ExhibitYou are receiving the same BGP Internet routes on R1 from both upstream ISPs.

In standard BGP operations, a router typically selects only one "best path" for a given destination prefix and installs that single path into the forwarding table. To utilize multiple paths for traffic forwarding (load-balancing), specific multipath features must be enabled.

BGP Multipath: This feature allows a router to install multiple equal-cost paths into the routing and forwarding tables. However, by default, BGP multipath requires that all candidate paths have the same neighboring Autonomous System (AS).

Multipath Multiple-AS (Option B): In the exhibit, R1 is receiving routes from ISP A (AS 65501) and ISP B (AS 65502). Since these are two different neighboring ASs, the standard multipath feature is not sufficient. You must use the multipath multiple-as statement under the BGP group or neighbor hierarchy. This tells Junos to consider paths as equal even if they originate from different neighboring ASs, provided all other BGP path selection attributes (Local Preference, AS Path length, Origin, MED, etc.) are identical.

Why other options are incorrect: * Option A (multihop) is used for peering with routers that are not directly connected.

Option C (prefix limit) is a security and stability feature to limit the number of prefixes received from a neighbor.

Option D (damping) is used to penalize unstable, "flapping" routes to prevent constant routing table churn.

Configuration Example for Junos OS 24.4: To implement this on R1, you would use the following configuration:

set protocols bgp group multipath multiple-as
