Refer to the exhibit.

The exhibit labels 10.25.1.50 as the cluster virtual IP address . The Study Guide explains that in HA configuration, “You must configure the HA group name, password, and the virtual IP only on the primary node.” It also says: “You must also configure an external interface for external communication and an IP address that will be used as a virtual IP for the whole cluster. Devices will interact with the cluster using this virtual IP.”

That is why the command for the primary node must point to the cluster virtual IP , not to the individual port1 addresses of the primary, secondary, or upstream firewall. In the exhibit, 10.25.1.30 is the primary node’s own port1 IP, 10.25.1.40 is the secondary node’s port1 IP, and 10.25.1.254 is the network device. The only address that matches the required cluster virtual IP is 10.25.1.50 , so the correct command is hc-settings -si iport1 -a10.25.1.50 .
