You are a network administrator that needs to setup a Data switch model S5248F-ON to be used for PowerStore 7000T system Use the Simulator to:

1) Check the OS version and license status.

2) Set management IP address 172.17.57.10 subnet as 255.255.255.0 on chassis = 1, slot = 1, port = 10

3) Enable the port

4) Configure default route with gateway 192.168.1.254, NTP server 192.168.1.50

5) Enable RSTP with priority 4096

6) Commit and exit.
