When an XtremIO X2 array is delivered, where is the cable shown in the exhibitconnected?

When an XtremIO X2 array is delivered, the cable shown in the exhibit should be connected to the middle USB ports in both X3-SC1 and X3-SC2. This is based on the standard configuration and setup for XtremIO X2 arrays as per the Dell XtremIO Deploy Achievement document. The middle USB ports are typically used for specific functions such as connecting to a management network or interfacing with other devices that are part of the storage array infrastructure.

The process for connecting the cable is as follows:

Identify the Correct Ports: Locate the middle USB ports on both X3-SC1 and X3-SC2. These ports are usually marked and differentiated from other USB ports by their position or labeling.

Connect the Cable: Insert the USB connector end of the cable into the middle USB port on X3-SC1 and then connect the other end to the corresponding port on X3-SC2. Ensure that the connection is secure and that the cable is not obstructing any other components or airflow.

Verify the Connection: Once connected, verify that the cable is recognized by the system. This can typically be done through the XtremIO Management Server (XMS) interface or by checking the system’s hardware configuration.

Check for Functionality: Ensure that the connected cable functions as intended. This may involve transferring data or accessing the management network, depending on the specific use case for the cable.

Reference Official Documentation: For detailed instructions and best practices, always refer to the official Dell XtremIO Deploy Achievement document1. This document provides comprehensive guidance on all aspects of setting up and managing XtremIO X2 arrays, including cable connections.

By following these steps and referring to the official documentation, you can ensure that the cable is connected correctly and that the XtremIO X2 array is set up for optimal performance and management.
